Beschreibung
| Farbe | Grau |
| Spezial-Farbe | Forge Grey |
| Grösse | One size |
| Material/Werkstoff | 6061-Aluminium |
| Einsatzbereich | Cargo |
| Geschlecht | uni sex |
| Dimension | 176 x 40.5 x 87 cm |
| Federweg | 70mm |
| Gänge | 14 |
| Innenlager | Motor integrated |
| Rahmen | Tern GSD, 6061-AL, patented MultiTruss design, EFBE Tri-Test approved: 200 kg |
| Gabel | Suntour custom for Tern, 1.5″ tapered Chromoly steerer, 32 mm stanchions, Thru-axle, , EFBE approved: 200 kg |
| Radgrösse | 20″ |
| Radsatz | Tern Atlas, heavy duty cargo wheel |
| Kurbelgarnitur | Tern GSD custom, Gates CDX CNC machined beltring |
| Schaltung | Rohloff E14 |
| Schalthebel | Rohloff E14, e-shift 14 spd |
| Kassette | Gates CDX, precision CNC machined cog |
| Kette | Gates Carbon Drive CDX belt |
| Power | 1000 Wh: 103-206 km |
| Bremse | Magura MT5, 4-piston hydraulic disc, 180 mm rotor |
| Bremsscheiben | 180mm / 180mm |
| Kettenführung/Kettenschutz | Tern Custom |
| Vorbau | Tern Andros (G2), adjustable, forged construction |
| Lenker | Tern Sweep, 6061-AL, Tern Andros adapted |
| Steuersatz | Tern Flux Pro Taper, 1.5″ |
| Sattelstütze | Cane Creek Thudbuster G4, Tern Telescope, 34.9/30.9 mm |
| Sattel | Tern GSD by Velo |
| Bereifung | F: Schwalbe Big Ben Plus, 55-406, Green Guard R: Tern x Schwalbe Super Moto-X, 62-406, Green Guard |
| Vorderradnabe | Tern Atlas, Boost Thru-Axle, sealed cart. bearing |
| Hinterradnabe | Rohloff E14, 526% range, Boost |
| Pedalen | Urban with non-slip surface, sealed bearings |
| Schutzblech | SplashGuard, AL6061, w/ Side Skirt |
| Ebike | true |
| Gepäckträger | Frame integrated, heavy duty design |
| Seitenständer | Tern LockStand, w/ remote unlock |
| Frontlicht | Tern High Beam, Ultra wide 700 lumens, Hi/Lo Beam |
| Rücklicht | Tern Brake Light, Always on brake light |
| Anzahl Gänge | Tern Brake Light, Always on brake light |
| Schloss | ABUS, keyed-alike with Bosch battery |
| Motor | Bosch Cargo Line, 400% Assist, 85 Nm Torque, max speed 25 kph |
| Batterie | Bosch Dual Battery system, Bosch PowerPack 2x500Wh |
| Display | Bosch Intuvia, Rohloff integrated shifting w/ auto downshift |
| Max. Systemgewicht | 200.00 Kilogramm |
| Felge | Tern Atlas, ultra wide 36mm, dual reinforced joint |
| Griffe/Lenkerband | Ergon |
| Gewicht | 37.26 Kilogramm |
